HP824L
CatCast
8543709990
Product Overview
HP824L MPEG4 AVC/H.264 HD IP Encoder is a professional HD audio & video encoding and multiplexing device. It has 12 HDMI (8/16/20/24 HDMI optional) video input interfaces, supporting MPEG-4 video encoding and MPEG 1 Layer 2 audio encoding. This device can simultaneously encode 12 (8/16/20/24 HDMI optional) channel HD audio & video; moreover, it has an IP output port can support 1MPTS and 12SPTS (8/16/20/24 SPTS) IP out. In conclusion, its high integrated and cost effective design makes the device widely used in varieties of digital distribution systems such as cable TV digital head-end, satellite digital TV broadcasting etc.
Key features
· 8× HDMI video inputs with 8 SPTS and 1 MPTS output through Data 1 or Data 2
· 12 × HDMI video inputs with 12 SPTS and 1 MPTS output through Data 1 or Data 2
· 16 × HDMI video inputs with 16 SPTS or 1 MPTS output through Data 1 or Data 2
· 20 × HDMI video inputs with 20 SPTS or 1 MPTS output through Data 1 or Data 2
· 24×HDMI video inputs with 24 SPTS or 1 MPTS output through Data 1 or Data 2
· Support MPEG4 AVC/H.264 video encoding format
· MPEG1 Layer II audio encoding format, support audio gain adjustment
· Support 1 ASI output (optional) as copy of MPTS
· Support IP output over UDP and RTP
· Support QR code, LOGO, OSD insertion
· support “Null PKT Filter” function
· Support PID Remapping
· Support PCR accurate adjusting
· Support PSI/SI editing and inserting
· Control via web management, and easy updates via web
· Lowest cost per channel, breakthrough price
Principle Chart
Technical specification
| Input | 12 HDMI inputs ( 8/16/20/24 input optional) | ||
Video |
Resolution | input | 1920x1080-60P,1920x1080-60i, 1920x1080-50P,1920x1080-50i, 1280x720-60i,1280x720-50p, 720x576-50i,720x480-60i |
output | 1920x1080-30p,1920x1080-25p, 1280x720-30p,1280x720-25p, 720x576-25p,720x480-30p | ||
| Encoding | MPEG-4 AVC/H.264 | ||
| Bit-rate | 1Mbps~13Mbps each channel | ||
| Rate Control | CBR/VBR | ||
| GOP Structure | IP…P (P Frame adjustment, without B Frame ) | ||
Audio | Encoding | MPEG-1 Layer 2 | |
| Sampling rate | 48KHz | ||
| Resolution | 24-bit | ||
| Audio Gain | 0-255 Adjustable | ||
| Bit-rate | 64kbps,128kbps,192kbps,224kbps,256kbps,320kbps,384kbps | ||
Multiplexing | Maximum PID Remapping | 180 input per channel | |
| Function | PID remapping ( automatically or manually) | ||
| Accurate PCR adjusting | |||
| Generate PSI/ SI table automatically | |||
Stream output | 12 SPTS(8/16/20/24SPTS) IP or 1MPTS output over UDP/RTP,1*1000 Base-T Ethernet interface ASI output(optional) as copy of MPTS | ||
| System | Network management(WEB) | ||
function | Chinese and English language | ||
| Ethernet software upgrade | |||
Miscellaneous | Dimension(W×L×H) | 482mm×410mm×44mm | |
| Approx weight | 8kg | ||
| Environment | 0~45℃(work)；-20~80℃（Storage） | ||
| Power requirements | AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz | ||
| Power consumption | 70W | ||
Technical Comparison
| HP808D/HP824H (HDMI) | HP824L | |
| Chipset | Fujitsu | Hisilicon |
| Video Channel | 8/12/16/20/24×HDMI optional | 4/8/12/16/20/24×HDMI optional |
Video Bit Rate | 0.8Mbps~19Mbps each channel (Bit rate is with a low fluctuation, suitable for cable system and satellite uplink) | 1Mbps~13Mbps each channel (Bit rate is with a high fluctuation, suitable for cable system, not suitable for satellite uplink) |
| GOP | IBBP | GOP Size=25 (without B Frame) |
Resolution | Up to 1080p-60 | Up to 1080P-30 (1080i/p-60/50 to 1080p-30/25 auto downscale convertion) |
Audio Encode | MPEG-1 Layer II; HE-AAC V2, LC- AAC Optional; AC3 passthrough | MPEG-1 Layer II |
| Audio Gain | 0-400 Adjustable | 0-255 Adjustable |
| ASI In & Mux | Yes | N/A |
| ASI output | Yes | Option as required |
IP output | SPTS and 1MPTS | SPTS and 1MPTS (for 4/8/12 channel) SPTS or 1MPTS (for 16/20/24 channel) |
