HPND9000
Catcast
Outline
HPND9000 network decoder using the most advanced core hardware decoding, to H.264 (HD and SD), MPEG2 (HD and SD), AVS+ and other mainstream video compression standard stream is decoded, in the harsh conditions of low network bandwidth also has excellent video and audio performance reduction.
Provides a wealth of stream media protocol, in order to adapt the network audio and video applications in various complicated environment HPND9000 such as RTMP, RTSP/RTP, HTTP, UDP etc.. The user can make a variety of rich configuration through the WEB page with equipment, in order to achieve optimal use effect. Can be widely used for cross-border point-to-point transmission, emergency communication, network video broadcast, remote conference, hotel VOD, campus radio, hospital expert consultation and many other application fields
Feature
High reliability,embed process,low power.
Low delay processing, Video decoding less than 300ms
Support 1080p@60fps decoding
input protocol support up to UDP, HTTP, RTSP/RTP, RTMP etc.
Support HD/SD-SDI,C HDMI,CVBS ,DVI,VGA output, analog video&audio output
Support H.264 HD video decoding, H.264/MPEG-2 SD video decoding
Support AAC, MPEG1 Audio Layer 2 Audio decoding
Friendly Man-Machine interface, WEB configuration ,7 Keys + LCD display indication
Specification
| Input | RJ45 interface | |
| Support UDP, HTTP, RTSP/RTP, RTMP streaming media protocol | ||
| Video decoding | Capacity | 1920x1080P60 |
| Support for deinterlacing,support H.264 BP/MP/HP@ level 5; support MVC | ||
| Support MPEG1 | ||
| Support MPEG2 SP@ML,MP@HL | ||
| Support MPEG4 SP@L0-3，ASP@L0-5，Support GMC | ||
| Support MPEG4 format (H.263 baseline) short head | ||
| Support Divx3/4/5/6 | ||
| Support for the AVS benchmark grade @ level 6, support AVS-P16 | ||
| Support RealVideo8/9/10 | ||
| Support VC-1 SP@ML,MP@HL,AP@L0-3 | ||
| Support VP6/8 | ||
| Audio decoding | Support G.711 audio decoding (u/a) audio decoding | |
| Support MPEG L1/L2 audio decoding | ||
| Support DRA/Real Audio decoding | ||
| Support DTS/DTS HD Core decoder | ||
| Support for AAC-LC, HE AAC V1/V2 decoder | ||
| Support for APE/FLAC/Ogg/AMR-NB/WB decoding | ||
| Output | Video | HD/SD SDI (BNC) |
| HDMI | ||
| DVI (DVI-I) | ||
| VGA (DVI-I) | ||
| CVBS (BNC) | ||
| Audio | HD/SD SDI embedded audio (BNC) | |
| HDMI embedded audio (BNC) | ||
| Stereo mono L-R channel analog audio (BNC) | ||
| Management | Front panel | LCD + 7 key equipment |
| Network | Network WEB browser directly access management | |
| General | Net Weight | 3KG |
| Size | Standard 1U | |
| Power | AC 110V-220V 50/60Hz | |
Outline
HPND9000 network decoder using the most advanced core hardware decoding, to H.264 (HD and SD), MPEG2 (HD and SD), AVS+ and other mainstream video compression standard stream is decoded, in the harsh conditions of low network bandwidth also has excellent video and audio performance reduction.
Provides a wealth of stream media protocol, in order to adapt the network audio and video applications in various complicated environment HPND9000 such as RTMP, RTSP/RTP, HTTP, UDP etc.. The user can make a variety of rich configuration through the WEB page with equipment, in order to achieve optimal use effect. Can be widely used for cross-border point-to-point transmission, emergency communication, network video broadcast, remote conference, hotel VOD, campus radio, hospital expert consultation and many other application fields
Feature
High reliability,embed process,low power.
Low delay processing, Video decoding less than 300ms
Support 1080p@60fps decoding
input protocol support up to UDP, HTTP, RTSP/RTP, RTMP etc.
Support HD/SD-SDI,C HDMI,CVBS ,DVI,VGA output, analog video&audio output
Support H.264 HD video decoding, H.264/MPEG-2 SD video decoding
Support AAC, MPEG1 Audio Layer 2 Audio decoding
Friendly Man-Machine interface, WEB configuration ,7 Keys + LCD display indication
Specification
| Input | RJ45 interface | |
| Support UDP, HTTP, RTSP/RTP, RTMP streaming media protocol | ||
| Video decoding | Capacity | 1920x1080P60 |
| Support for deinterlacing,support H.264 BP/MP/HP@ level 5; support MVC | ||
| Support MPEG1 | ||
| Support MPEG2 SP@ML,MP@HL | ||
| Support MPEG4 SP@L0-3，ASP@L0-5，Support GMC | ||
| Support MPEG4 format (H.263 baseline) short head | ||
| Support Divx3/4/5/6 | ||
| Support for the AVS benchmark grade @ level 6, support AVS-P16 | ||
| Support RealVideo8/9/10 | ||
| Support VC-1 SP@ML,MP@HL,AP@L0-3 | ||
| Support VP6/8 | ||
| Audio decoding | Support G.711 audio decoding (u/a) audio decoding | |
| Support MPEG L1/L2 audio decoding | ||
| Support DRA/Real Audio decoding | ||
| Support DTS/DTS HD Core decoder | ||
| Support for AAC-LC, HE AAC V1/V2 decoder | ||
| Support for APE/FLAC/Ogg/AMR-NB/WB decoding | ||
| Output | Video | HD/SD SDI (BNC) |
| HDMI | ||
| DVI (DVI-I) | ||
| VGA (DVI-I) | ||
| CVBS (BNC) | ||
| Audio | HD/SD SDI embedded audio (BNC) | |
| HDMI embedded audio (BNC) | ||
| Stereo mono L-R channel analog audio (BNC) | ||
| Management | Front panel | LCD + 7 key equipment |
| Network | Network WEB browser directly access management | |
| General | Net Weight | 3KG |
| Size | Standard 1U | |
| Power | AC 110V-220V 50/60Hz | |
