HPS384A
Catcast
Outline
HPS384A ISDB-T modulator is developed to adapt Japan, Brazil, Argentina and other South American country’s terrestrial digital television. The modulator's channel encoding and modulation mode is fully complying with the ARIB STD-B31 standard. This ISDB-T modulator supports four ASI hot backup input, single frequency network, and multi-frequency network. In order to improve the output performance of the transmitter, this ISDB-T modulator also simultaneously supports adaptive linear and nonlinear digital pre-distortion, layered transmission and three transmission modes. Furthermore, this device can be upgraded and controlled through network system, which can be widely used in ISDB-T digital broadcasting network's setting up and set-top box design's production and test.
Features
1. Fully complying with ISDB-T (ARIB STD-B31) and ISDB-TB standard
2. 4 ASI in, 1 RF in, 10MHz reference clock and 1PPS in
3. Layered transmission with A, A+B, A+B+C hierarchy modes
4. ISDB-T BTS input (with IIP packet), support single frequency and multi-frequency network
5. Three transmission modes: mode1(2k), mode2(4k), mode3(8k)
6. Supports adaptive linear digital pre-distortion (DPD)
7. Supports adaptive non-linear digital pre-distortion (DPD )
8. MER≥42db
9. RF output range: 30~960MHz with 1Hz step
10. Constant temperature crystal oscillating and excellent frequency stability (reach up to 0.1ppm)
11. LCD display, keyboard and SNMP software operation
Specifications
| Input | 4 ASI input, hot backup, BNC interface | |
| GPS 10MHz reference clock input, BNC interface | ||
| GPS 1PPS input, BNC interface | ||
| 1 RF input for DPD -25dbm~+5dbm | ||
| Modulation | Standard | ARIB STD-B31 |
| Mode | mode 1(2k), mode 2(4k), mode 3(8k) | |
| Constellation | DQPSK, QPSK, 16QAM, 64QAM | |
| External coding | RS (204，188) | |
| Internal coding | Convolution (1/2, 2/3, 3/4, 5/6, 7/8) | |
| Guard interval | 1/4, 1/8, 1/16, 1/32 | |
| Hierarchy mode | A、A+B、A+B+C | |
| Time domain interlacing | mode 1: 0, 4, 8, 16 mode 2: 0, 2, 4, 8 mode 3: 0, 1, 2, 4 | |
| Bandwidth | 6MHz, 7MHz, 8MHz | |
| RF Out | Connector | N Type, 50ΩImpedance |
| RF range | 30~960Mhz，1Hz step | |
| Output level ATT | -26dbm~+3dbm，0.1db step | |
| MER | ≥ 42db | |
| Non-linear DPD | over 10db ACPR improvement (normally) | |
| linear DPD | over 10db non-flatness adjustment(normally) | |
| System | LCD display, keyboard and SNMP operation | |
| Supporting software upgrading through network | ||
| General | Demission (W*L*H) | 440mm×414mm×44.5mm |
| Weight | 4.9kg | |
| Temperature | 0~45℃(operation),-20~80℃(storage) | |
| Power supply | AC 100V~240V,50/60Hz | |
| Consumption | To be tested | |
