HPS3402F
Catcast
85437099
HPS3402F High-Performance Modulator DVB-S2if Output
HPS3402F is a high-performance modulator developed according to DVB-S2 (EN302 307) standard which is the standard of second generation of the European broadband satellite telecommunication. It is to convert the input ASI and IP signals alternatively into digital DVB-S2 IF output.
BISS scrambling mode is inserted to this DVB-S2 modulator, which helps to safely distribute your programs. It is easy to reach local and remote control with NMS software and LCD in the front panel.
With its high cost-effective design, HPS3402F DVB-S2 modulator is wildly used for broadcasting, interactive services, news gathering and other broadband satellite applications.
Features:
* Fully complying with DVB-S2 (EN302 307) and DVB-S (EN300 421) standard
* 4 ASI inputs (3 ASI for hot backup)
* Support IP signal input
* Constant temperature crystal oscillator, as high as 0.1ppm stability
* Support 1 external 10MHz reference clock input with loop out
* Support BISS scrambling
* Support local and remote control
* Output frequency range: 50~800MHz, 1KHz stepping
Specifications:
| ASI Input | Supporting Both Packet And Byte Mode TS Input | ||
| 4 ASI input ( 3 ASI for hot backup) | |||
| Supporting 188/204Byte Transmission Stream Packet | |||
| ASI Input Connector: BNC, Impedance 75Ω | |||
| IP Input | 1*IP Input (Rj45, 100M TS Over UDP) | ||
| 10MHz Input | 1*10Mhz Input (BNC Interface) | ||
| IF Output | Range: 50 to 800 MHz, 1KHz stepping | ||
| Output Level Attenuation: 0dBm~31.5 dBm, 0.5dB Stepping | |||
| MER≥40dB | |||
| Connector: N type, impedance 50Ω | |||
| Channel Coding and Modulation | DVB-S | DVB-S2 | |
| Outer coding | RS Coding | BCH Coding | |
| Inner coding | Convolution | LDPC Coding | |
| FEC/ Convolution Rate | 1/2, 2/3, 3/4, 5/6, 7/8 | QPSK: 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 | |
| Constellation | QPSK | QPSK,8PSK | |
| Roll-off Factor | 0.2, 0.25, 0.35 | 0.2, 0.25, 0.35 | |
| Symbol Rate | 0.5~45MBauds | 0.5~30MBauds | |
| BISS Scramble | Mode0, mode1, mode E | ||
| Miscellaneous | Dimension | 482mm×410mm×44mm | |
| Weight | 4.3 KG | ||
| Temperature | 0~45℃(operation), -20~80℃ (storage) | ||
| Power | 100-240VAC±10%,50Hz-60Hz | ||
| Consumption | 25W | ||
Principle Chart:
Technical Comparison
| HIPRO HPS3402F | OTHER PRODUCT | |
| Input | 4 ASI in with hot backup | 2 ASI in with hot backup |
| Frequency Out Range | 50 - 800 MHz | 36 - 1000 MHz |
| MER | MER≥40dB | MER> 38dB |
| Output Level | 0dBm~31.5 dBm | 0dBm~20 dBm |
| Symbol Rate | 0.5~45MBauds | 1~18MBauds |
| BISS Scramble | Support | Not support |
Constant Temperature Crystal Oscillator | Support | Not support |
| CID Insert | Support | Not support |
