HPS864
Catcast
HPS864 8×DVB-S/S2 to 64×SPTS IP Gateway
Overview
HPS864 DVB-S/S2 IP receiver (IRD) is one of the main equipments for digital TV head-end. It can receive 8 channels DVB-S/S2 signal (RF) transponders and output 64×SPTS IP transport stream (TS over UDP). It can convert 64 programs and is mainly applied to IPTV live broadcast system.
Features
8×DVB-S or 8×DVB-S2 RF (optional) input
64×SPTS (Gigabit, Multicast, TS over UDP) output
Maximum 188×7package supported
LCD/Keyboard control by front panel and network management by Ethernet
Technical Specification
| Input | 8×RF | F-head |
| Demodulation Mode | DVB-S/S2, QPSK/8PSK | |
| Symbol Rate | 1~45 Mbaud/s | |
| Frequency Range | 950MHz~2150MHz | |
| Error Correction Coding | RS coding 188/204 | |
| Output | IP | 64×SPTS/Unicast/1000BASE-T, TS over IP/UDP |
| Control | NMS (Ethernet port, RJ-45), Keyboard + LCD | |
General Features | Size | 482mm×410mm×44mm |
| Temperature Range | 0~45°C (Operation); -20~80°C (Storage) | |
| Power | 100-240VAC, 50Hz, 25W | |
