HP824IU
Catcast
Stable Bitrate 24 HDMI HEVC H.265 MPEG4 AVC H.264 to DVB-C DVB-T ATSC ISDB-T Modulation Encoder Modulator
Product Overview
HP824IU is a professional high integration device which includes encoding, multiplexing, and modulation in one body. It supports up to 24 HDMI input, one DVB-C/T/ISDB-T (ATSC optional) tuner input and up to 512 IP input for re-mux. After multiplexing, it output 16 non-adjacent ISDB-T carries. It also supports 16 MPTS as mirror of 16 carriers through Data2 (GE) port. This full functionality makes it ideal for small CATV head end system, and it’s a smart choice for hotel TV system, entertainment system in sports bar, hospital, apartment…
Key features
· 8/12/16/20/24× HDMI input with HEVC/H.265, MPEG4 AVC/H.264 video encoding format
· Support B frame GOP, high video compression ratio and stable bitrate
· MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2 audio encoding, AC3 Pass-through
· Support 16 groups multiplexing/ISDB-T modulating channels out
· Support 1 ASI out as mirror of one of RF output carriers—Optional
· Support 16 MPTS IP output over UDP, RTP/RTSP
· Support LOGO, Caption and QR code insertion (Language Supported: 中文, English, العربية, ไทย, हिन्दी, руская, اردو, for more languages please consult us…)
· Support PID remapping/ accurate PCR adjusting/PSI/SI editing and inserting
· Control via web management, and easy updates via web
Principle Chart
DVB-C Principle Chart
DVB-T/ATSC Principle Chart
ISDB-T Principle Chart
Technical Specification
Input | 8/12/16/20/24 HDMI inputs for option 1 DVB-C/T/ISDB-T (ATSC optional) Tuner for re-mux, F type interface 512 IP input over UDP and RTP, DATA1, RJ45—DVB-C RF out 256/512 IP input over UDP and RTP, DATA1, RJ45—DVB-T/ATSC RF out 192/512 IP input over UDP and RTP, DATA1, RJ45—ISDB RF out | ||||
Video | Resolution | Input | 1920×1080_60P, 1920×1080_50P, 1920×1080_59.94P, 1920×1080_60i, 1920×1080_50i, 1920×1080_59.94i, 1280×720_60P, 1280×720_59.94P, 1280×720_50P | ||
Output | 1920×1080_60P , 1920×1080_50P, 1920×1080_30P, 1920×1080_25P, 1280×720_60P，1280×720_50P | ||||
Encoding | MPEG-4 AVC/H.264, HEVC/H.265 | ||||
Bit-rate | 1~15Mbps for each channel | ||||
Rate Control | CBR/VBR | ||||
GOP Structure | IP, IBBP, IBBBP | ||||
Audio | Encoding | MPEG-1 Layer 2, LC-AAC, HE-AAC, HE-AAC V2; AC3 Pass-through | |||
Sampling rate | 48KHz | ||||
Audio Delay | -400—-1000ms | ||||
Bit-rate | 48Kbps~384Kbps (MPEG-1 Layer 2 & LC-AAC) 24 Kbps~128 Kbps (HE-AAC) 18 Kbps~56 Kbps (HE-AAC V2) | ||||
Multiplexing | Maximum PID Remapping | 180 input per channel | |||
Function | PID remapping ( automatically or manually) | ||||
Accurate PCR adjusting | |||||
Generate PSI/ SI table automatically | |||||
Scrambling | Maximum simulcrypt CA | 4 | |||
Standard | ETR289, ETSI 101197, ETSI 103197 | ||||
Connection | Local/remote connection | ||||
Modulation | DVB-C | QAM Channel | 16/32 non-adjacent carriers output (maximum bandwidth 192MHz) | ||
Standard | EN300 429/ITU-T J.83A/B | ||||
MER | ≥40db | ||||
RF frequency | 50~960MHz, 1KHz step | ||||
RF output level | -20~+10dbm (87~117 dbµV), 0.1db step | ||||
Symbol Rate | 5.0Msps~7.0Msps, 1ksps stepping | ||||
J.83A | J.83B | ||||
Constellation | 16/32/64/128/256QAM | 64/256 QAM | |||
Bandwidth | 8M | 6M | |||
DVB-T | Standard | EN300744 | |||
FFT mode | 2K,4K, 8K | ||||
Bandwidth | 6M, 7M, 8M | ||||
Constellation | QPSK, 16QAM, 64QAM | ||||
Guard Interval | 1/4, 1/8, 1/16, 1/32 | ||||
FEC | 1/2, 2/3, 3/4, 5/6, 7/8 | ||||
MER | ≥42 dB | ||||
RF frequency | 50~960MHz, 1KHz step | ||||
RF out | 8/16 non-adjacent carriers output (maximum bandwidth 192MHz) | ||||
RF output level | -20~ +10 dBm (87~117 dbµV), 0.1db step | ||||
ATSC | Standard | ATSC A/53 | |||
Bandwidth | 6M | ||||
Constellation | 8VSB | ||||
FEC | RS(208 188)+Trellis | ||||
MER | ≥40dB | ||||
ACL | -55 dBc | ||||
RF frequency | 50~960MHz, 1KHz step | ||||
RF out | 8/16 non-adjacent carriers output (maximum bandwidth 192MHz) | ||||
RF output level | -20~+10dbm (for all carriers), 0.5db stepping | ||||
ISDB-T | Standard | ARIB STD-B31 | |||
Bandwidth | 6M | ||||
Constellation | QPSK, 16QAM, 64QAM | ||||
Guard Interval | 1/32, 1/16, 1/8, 1/4 | ||||
Transmission Mode | 2K, 4K, 8K | ||||
Code rate | 1/2, 2/3, 3/4, 5/6, 7/8 | ||||
MER | ≥40dB | ||||
RF frequency | 50~960MHz, 1KHz step | ||||
RF out | 12/16 non-adjacent carriers output (maximum bandwidth 192MHz) | ||||
RF output level | -20dBm~+10dBm, 0.1dB stepping | ||||
Stream output | 1 ASI output as mirror of one of RF output carriers-Optional 16/32 MPTS output over UDP and RTP/RTSP as mirror of 16/32 DVB-C carriers, 8/16 MPTS output over UDP and RTP/RTSP as mirror of 8/16 DVB-T/ATSC carriers(Optional) 12/16 MPTS output over UDP and RTP/RTSP as mirror of 12/16 ISDB-T carriers(Optional) 1*1000M Base-T Ethernet interface | ||||
System function | Network management (WEB) | ||||
Chinese and English language | |||||
Ethernet software upgrade | |||||
Miscellaneous | Dimension (W×L×H) | 482mm×440mm×44mm | |||
Environment | 0~45℃(work)；-20~80℃（Storage） | ||||
Power requirements | AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz | ||||
