HPR3564H
Catcast
HPR3564H DVB-T ASI IP Input Mux BISS with CAM CI to IP ASI IRD Decoder
Summary
HPR3564H DVB-T/(T) HD IRD is all-in-one device which integrates demodulation, de-scrambler, re-mux and decoding in one case to convert RF signals into audio/video, (CVBS/YPbPr/HDMI/SDI) output. It is a 1-U case which supports 2 tuner inputs to receive signal from satellite, cable or terrestrial devices. The two CAMs/CIs accompanied and BISS modules can descramble the programs input from encrypted RF, ASI and IP. Its pluggable structure design greatly facilitates the change of modules (demodulator or decoder) as needed. To meet customers’ various requirements, HPR3564H is also equipped with ASI and IP input for re-mux, and output with 2 ASI ports and IP port.
Key Features
● Demodulation + descrambler +re-mux+decoder modules in one box
Specification
Input
| 2 x DVB-T/(T) RF, F type |
| 1×ASI input for re-mux, BNC interface |
| 1xIP input for re-mux (UDP) |
| Input Frequency | 30MHz ~999.999 MHz |
| Bandwidth | 6/7/8 M bandwidth |
| Descrambling | |
| CAM/CI Quantity | 2 |
| BISS Mode | Mode 1, Mode E (up to 120Mbps) |
| IP Output | 1*MPTS & 8*SPTS over UDP, RTP/RTSP. 100 Base-T Ethernet interface (unicast / multicast) |
| 2×ASI | BNC interface, mirrored out |
| Decode Output | Video Interface: 1xCVBS/YPbPr/HDMI/SDI Video Decode: MPEG-2; MPEG4 AVC/H.264 Resolution: 480i, 480p, 576i, 576p, 720p@50/59.94/60, 1080i@50/59.94/60 Chroma: 4:2:0 Audio Interface: 2 x Stereo/4xmono, HDMI, SDI Audio Decode: MPEG 1 Layer II, LC-AAC, HE-AAC, Dolby Digital/ Dolby Digital Plus Audio Output Mode: Left, Right, Stereo, 5.1 CH (for HDMI/SDI out only) |
| Local interface | LCD + control buttons |
| Remote management | Web-server Management |
| Language | English |
| Upgrade | USB, web management |
| Power supply | AC 100V~240V |
| Dimensions | 482*300*44.5mm |
| Weight | 3 kgs |
| Operation temperature | 0~45ºC |
Principle Chart
